Niton™ XL3t GOLDD+ Handheld XRF Analyzer
The Peak of Handheld Performance: Maximum Sensitivity for Light Elements.
The Niton XL3t GOLDD+ is engineered for high-stakes applications where accuracy cannot be compromised. Featuring the most powerful X-ray tube available in a handheld format and advanced GOLDD+ technology, this analyzer identifies light elements (Mg, Al, Si, P, S) up to 10 times faster than standard detectors—all without the need for expensive helium purging or vacuum pumps.
- Ultra-Fast Results: Drastically reduce testing time with the most responsive detector in the Niton family.
- 50kV Power: Superior excitation for heavy elements and deeper penetration for complex samples.
- Tilt-Screen Ergonomics: Features a high-resolution tilting display for easy reading at any angle.
- No Accessories Required: Lab-quality light element analysis in the palm of your hand, straight out of the box.
Why the XL3t GOLDD+ is the Expert’s Choice
At XRF Dubai, we recommend the Niton XL3t GOLDD+ for clients who require “the best of the best.” It bridges the gap between field-portability and laboratory-grade precision.
1. Advanced Mining & Geochemical Soil Testing
In mining and exploration, the ability to detect subtle anomalies is critical. The XL3t GOLDD+ excels at identifying trace elements and contaminants in soil testing (such as Arsenic or Chlorine). Its sensitivity allows geologists to perform real-time ore blending and geochemical mapping with confidence that matches traditional lab results.
2. High-Performance Scraps and Recycling
For the recycling industry, this unit is a profit multiplier. It easily sorts complex Aluminum, Titanium, and Bronze alloys that other machines might miss. Its ability to detect “tramp” and trace elements ensures that your scraps are graded with 100% accuracy, preventing costly downgrades at the foundry.
3. Professional Gold Checking & Precious Metals
When dealing with high-value bullion and jewelry, the XL3t GOLDD+ provides an exhaustive elemental breakdown. Beyond simple gold testing, it identifies alloying elements and potential prohibited substances, making it the ultimate tool for refineries and high-volume gold checking centers in Dubai.
4. Integrated Visual Guidance
The built-in CCD camera allows you to pinpoint exact testing locations on a sample. Whether you are testing a specific weld point or a small jewelry component, you can see exactly what you are analyzing and store the image alongside your data.
Technical Specifications
| Feature | Details |
| Detector | GOLDD+ (Geometrically Optimized Large Area Drift Detector) |
| X-Ray Tube | Ag anode 50 kV / 200 µA (Highest Power Handheld) |
| Weight | 1.3 kg (2.9 lb) – Industry-leading power-to-weight ratio |
| Display | Tilting color touch-screen for superior visibility |
| Analytical Range | Up to 30 elements from Mg to U |
| Light Elements | Magnesium (Mg) to Sulfur (S) without Helium/Vacuum |
| Connectivity | USB, Bluetooth™, and RS-232 |
| System CPU | 533 MHz ARM 11 (High-speed processing) |
Functional Modes & Software
- Specialized Modes: Alloy (Precious Metals), Bulk (Soil/Mining), and Plastic (RoHS/Toys).
- Data Management: Niton Data Transfer (NDT™) suite for remote operation and custom certificates.
- Visual Documentation: Integrated camera for sample location and data storage.
- Durability: Sealed against moisture and dust for harsh industrial use.
