Description
Why the X-200 is the “First Choice” for Professional Testing
At XRF Dubai, we recommend the SciAps X-200 for operations that need lab-quality results on complex alloys and geological samples without the “elite” price tag.
1. Advanced Scraps and Recycling (Aluminum Focus)
The X-200 is rapidly becoming the industry standard for scraps and recycling. Unlike basic models, it is incredibly fast on every alloy family, including difficult aluminum grades. Its ability to accurately measure light elements ensures you can separate 6061 from 6063 or check for trace contaminants in stainless steel with total confidence.
2. Comprehensive Mining and Soil Testing
For mining exploration, the X-200 offers a full suite of elements for pathfinder, exploration, and ore blending. When used for soil testing, it excels at environmental screening, detecting heavy metal contaminants and light elements in sediment and soil samples instantly. It supports EPA Method 6200 and custom empirical calibrations for site-specific accuracy.
3. Professional Gold Testing and Precious Metals
In the Dubai precious metals market, the X-200 provides a non-destructive solution for comprehensive gold checking. It doesn’t just verify gold purity; it analyzes the entire elemental composition of jewelry, coins, and bullion, ensuring no trace element or alloying metal goes undetected.
4. Smart Tech for Harsh Environments
Built for the field, the X-200 thrives in the heat. It features an Android-based OS for a smartphone-like user experience, complete with WiFi, Bluetooth, and GPS for field mapping. The “Hot-Swap” battery capability means your team never has to stop testing to change power packs.
Technical Specifications
| Feature | Details |
| Weight | 1.4 kg (3.1 lbs) with battery |
| X-Ray Tube | 5W Tube (Up to 50kV, 200uA) – Rh or Au Anode |
| Detector | 20mm² High-Performance Silicon Drift Detector (SDD) |
| Analytical Range | Mg, Al, Si, P, S, Ti, V, Cr, Mn, Fe, Co, Ni, Cu, Zn, and many more |
| Operating System | Android OS with 3.5″ color touchscreen |
| Internal Calibration | Automatic via internal 316 Stainless Shutter |
| Connectivity | WiFi, Bluetooth, USB, and SciAps Cloud |
| Battery | Li-ion with Hot-Swap capability (60s swap time) |
| Environment | -12°C to 54°C (10°F to 130°F) |
Available Apps & Calibration
- Alloy & PMI: Optimized for Aluminum, Stainless, and Red Metals.
- Mining & Geochem: Pathfinder, Environmental, and Exploration suites.
- Soil: Geo-Env Soil testing for hazardous heavy metals.
- Compliance: RoHS and Restricted Substances (Halogen-free testing).
- Precious Metals: Specialized gold testing and jewelry analysis.
Standard Accessories: Locking shielded carrying case, two Li-ion batteries, 110/220V charger, safety lanyard, and SciAps Profile Builder PC software.
