Description
Why the SciAps X-5 is the Smartest Value for Your Business
At XRF Dubai, we recommend the X-5 for users who want modern, high-speed hardware but don’t require the measurement of light elements. It is a “Classic, Reimagined” for today’s high-tech industrial world.
1. Precision Scraps and Recycling
The X-5 is a powerhouse for scraps and recycling. It provides lightning-fast verification of stainless steels, high-temp alloys, and red metals. Whether you are sorting Cr/Mo steels or corrosion-resistant alloys, the X-5 delivers reliable results in seconds, ensuring your yard stays productive and profitable.
2. Reliable Gold Testing and Precious Metals
For the gold checking market, the X-5 offers exceptional accuracy. It quickly determines the purity of gold, silver, and platinum group metals. Its small size makes it easy to handle in retail or refinery settings, and the integrated camera ensures you are targeting the exact spot on a piece of jewelry or a bullion bar.
3. Mining, Soils, and Exploration
In mining and soils applications, the X-5 excels at heavy metal analysis and transition metal detection. It is a rugged tool for geochemical mapping, providing the data you need to identify ore bodies and mineral trends directly in the field.
4. Built for Extreme Environments
Dubai’s climate can be brutal on electronics. SciAps has re-engineered the internal circuit boards and housing of the X-Series to ensure the device doesn’t “drift” or shut down when the temperature rises, making it a reliable partner for outdoor work in the UAE.
Technical Specifications
| Feature | Details |
| Weight | 1.35 kg (2.98 lbs) with battery |
| X-Ray Tube | 4W, 40kV (or 5W, 50kV) with Rh, Au, or W anode |
| Detector | 7 mm² Silicon Drift Detector (SDD) |
| Operating System | Android OS with smartphone-style interface |
| Display | 2.7-inch color capacitive touchscreen |
| Connectivity | WiFi, Bluetooth, USB, and SciAps Cloud |
| Cameras | Integrated high-res camera + Macro-camera for barcodes |
| Pulse Processor | 12-bit with 80 MSPS digitization rate |
| Dimensions | 21.6 x 24.1 x 6.1 cm (8.5 x 9.5 x 2.4 in) |
Core Applications & Apps
- Alloy & PMI: Verification of stainless, low-alloy, and red metals.
- Precious Metals: Professional gold testing and karat identification.
- Environmental: Soil testing, RoHS screening, and lead paint detection.
- Specialized: Car catalysts and mining exploration.
